Custom Solenoids and Valves for Proportional Applications

Proportional solenoids and proportional solenoid valves are often used in applications requiring variable and precise control. By converting an electric control signal into proportional mechanical force, proportional solenoids are able to achieve varying position and force.

Discrete Proportional Valve System

Uses an intelligent combination of simple binary (ON/OFF) solenoid valves with varied port size to achieve stepped proportional control.

Proportional Pneumatic Control Valve

This pneumatic control valve was designed to meter inlet and outlet pressure to proportionally control an actuator.

Proportional Pressure Relief Valve

This direct-acting, normally open, proportional pressure relief valve can be designed to operate over various pressure ranges.

Three-Way Proportional Pressure Reducing-Relieving Valve

This proportional solenoid valve is a direct-acting, normally open, continuously variable pressure relief valve.

Canister Proportional Purge Solenoid Valve

This example of a pulse width modulated, proportional flow control solenoid valve is used in a vehicle's emission control system.

Proportional Solenoid Actuator

This proportional solenoid actuator (used to power proportional hydraulic valves in off-highway applications) is direct-acting and continuously variable.

Proportional Pressure Reducing Relieving Valve

This continuously variable pressure reducing relieving valve can be designed to operate over various pressure ranges to optimize controllability.

View All Solenoids and Valves
