Solenoids at Work in SCR Systems

Diesel engine manufacturers are utilizing Selective Catalytic Reduction (SCR) technology to meet more stringent emissions regulations. These SCR systems use diesel exhaust fluid, better known as AdBlue®, injected into the exhaust stream to create a chemical composition that changes the exhaust into a mixture of nitrogen and oxygen.

Customer Problem

Diesel engine manufacturers utilize Selective Catalytic Reduction (SCR) technology to meet more stringent emissions regulations. These SCR systems use diesel exhaust fluid, better known as AdBlue®, injected into the exhaust stream to create a chemical composition that changes the exhaust into a mixture of nitrogen and oxygen.

The TLX Solution

TLX was awarded a production contract for this coolant control valve for use in a Diesel Exhaust Fluid (DEF) Reservoir System. The system thaws diesel exhaust fluid during freezing conditions.

View Design Solution

Coolant Control Valve

Operating range: 12-24 Vdc

Maximum fluid flow rate: .5 l/sec (8 gpm)

Coolant temperature range: -40 to 110°C

Current draw: 2.5 amps max

Response time: < 1 sec

Maximum pressure: 500 kPa (73 psi)

All TLX components are customized to fit system requirements, meaning technical specifications are unique to each customer and design. Examples given on our website are for illustration purposes only.

Working with TLX

Experienced partner of industry leaders, first-tier suppliers, and OEMs
Direct access to our design and engineering team
Localized production in USA and China
Dependable single-source solution from design to delivery

Have questions or ready to get started?

Contact Our Engineers

Our Process

Step 1 / Initial Review

Our engineering team works directly with you to determine the viability of your program and identify the best solution based on your specifications.

Step 2 / Quote

Quotes include all costs related to your project - tooling, prototype, piece part, production and project specific costs.

Step 3 / Design Review & Prototypes

Our engineering team reviews the design with you and makes any adjustments needed. Prototypes are built according to design specifications for testing.

Step 4 / Testing

Prototypes are tested according to your specifications, with all relevant test data provided to you for evaluation.

Step 5 / APQP

DFMEA’s, PFMEA’s, control plans and process flow diagrams are started to drive the product intent design.

Step 6 / Pre-Production

Working drawings are developed for production. A second prototype build and a set of production parts are made from tooling and thoroughly tested.

Step 7 / PPAP/Production

The final design along with the PPAP (Production Part Approval Process) is developed and the new product enters production.

Step 8 / Ongoing Improvements

Our team collaborates with you to continue making improvements to the product to best meet your needs, increasing efficiency and reducing cost.
