Large Latching Solenoid

This latching solenoid uses inherent residual magnetism or permanent magnets to maintain either of its positions without consuming power.

Designed to help avoid equipment damage when power needs to be interrupted or switched in a high-voltage environment, this heavy-duty solenoid has high latching forces (100–300 lbs.) and is typically 2.75”–4.25” in diameter. Its size, stroke, and latching force can all be customized to meet application requirements. This solenoid can also be designed with a permanent magnet instead of using the solenoid's inherent residual magnetism.

Features and Benefits

  • High latching forces
  • Residual or permanent magnet
  • Low power consumption
  • Fast response
  • Temperature stable
  • Customizable configuration
  • Can be designed for specific load holding capability

Specifications

All TLX components are customized to fit system requirements, meaning technical specifications are unique to each customer and design. Examples given on our website are for illustration purposes only.

Is our Large Latching Solenoid the right fit for your application?

TLX Technologies partners with the world’s top brands, first-tier suppliers, and OEMs. Contact our engineers today to discuss the details of your project.

Achieve Immediate Response in a Fault-Interrupting Device

These large latching solenoids with high latching force were designed for a manufacturer of high-voltage power distribution equipment to disconnect power quickly to prevent equipment damage.

Our engineers begin by designing with 3D CAD and performing electromagnetic and fluid dynamic analysis with state-of-the-art finite element analysis software. Every design is engineered and tested in our lab to meet our customers’ specifications.

Increased Performance

Precise control with high accuracy through tighter tolerances. Reducing friction and inefficiencies provides extremely low hysteresis.

Lighter Weight

Multiple variables in the design and manufacturing process are optimized to reduce overall weight and size of the solenoid or valve.

Minimized Footprint

Custom solenoids can be designed to utilize the best control scheme for your application, resulting in a minimized footprint.

Limited Power Consumption

Latching technology in solenoid and valve design minimizes overall power consumption.

Extreme Environments

Can be designed to meet extreme environments that include moisture, dirt/dust, vibration and/or extreme temperature requirements.

Built-in Safety

Failsafe modes are designed into solenoids and valves utilizing integrated electronic controls.
