A Battery-Powered Valve for Smart Water Meters
Customer Problem
A manufacturer needed a valve to control the flow of water through their smart water meters, but they were having trouble finding a solution that matched all of their requirements. They needed an extremely low-voltage pilot valve that could operate in a wide range of temperatures and handle high mechanical shock loads without changing state. Because the valve would handle drinking water, it also needed to be NSF certified.
The TLX Solution
TLX Technologies designed a battery-powered diaphragm latching solenoid valve. This valve used a small solenoid with a comparatively high latching force to open and close an orifice in the diaphragm. This changed the pressure on either side of the diaphragm, allowing water pressure to open and close the main valve rather than the solenoid. The valve was designed to meet the requirements for NSF certification.
Latching Diaphragm Solenoid Valve
- Operating temperature range
- 2°C to 35°C (35.6°F to 95°F)
- Operating pressure
- 137.9 to 1206.6 kPa
- Operating voltage
- 2.9 to 3.6 Vdc
- Working stroke
- 0.48 mm ± 0.10 mm
- Coil resistance at 25°C
- 7.4 Ω
- Current draw
- 500 mA max.
Every TLX solution is custom engineered to meet the requirements of its application. Technical specifications shown on this website are intended to illustrate typical performance and design characteristics.
