Improving Welding Clamps with Latching Technology

TLX designs solenoids that solve our customers' unique dilemmas. This is an example of how TLX ingenuity was applied in the field.

Customer Problem

A manufacturer needed to replace the pneumatically powered clamps that held material for welding. After welding was complete, the solution would release and allow the material to move down the line. In addition, the clamp replacement needed to be precise, holding each piece in a precise position.

TLX Solution

A custom latching solenoid provided both the locking and latching functions the manufacturer required. Permanent magnets latched the solenoids in a retracted position without consuming power. While retracted, material could be positioned in the fixture for welding. A short pulse of power un-latched the solenoids, canceling the magnet and holding the part down with a heavy duty spring. When the welding was complete, a short pulse of opposite polarity returned the solenoids to the retracted position, releasing the part down the production line. The custom solenoids easily replaced the pneumatic clamps, providing an energy efficient solution.

Click to learn more about this custom component.
