Latching Solenoid

Used only a short voltage pulse to actuate and maintained position without constant power.

This latching solenoid actuated to the latched position with a short voltage pulse of one polarity and was held in the latched position by a permanent magnet. A voltage pulse of the opposite polarity canceled the magnetic field of the permanent magnet, and a spring returned the solenoid to the de-latched position.

Typical Applications

Latching Solenoid 200615 155845

Features and Benefits

  • Compact design
  • Low power consumption
  • Load shifting capability can be specified
  • Configurable to meet application power requirements
  • Ideal for battery-operated applications
Downloads

All TLX components are customized to fit system requirements, meaning technical specifications are unique to each customer and design. Examples given on our website are for illustration purposes only.

Is our Latching Solenoid the right fit for your application?

TLX Technologies partners with the world’s top brands, first-tier suppliers, and OEMs. Contact our engineers today to discuss the details of your project.

Improving Oil Change Efficiency with Solenoids

This latching solenoid provided precise control over the amount of oil dispensed by an oil dispensing meter without any waste.

TLX Technologies is the go-to partner for the design and development of tomorrow's most advanced industrial equipment and systems.

High Force, Long Stroke

When a high force coupled with a long stroke is required, custom solenoids designed by TLX offer an economical, long-lasting and durable solution.

Durable and Robust

To do the heavy work needed by many industrial applications, TLX’s designs industrial work solenoids for durability and strength.

Extreme Environments

Design and optimization of solenoids and valves for environments including moisture, dirt and dust, vibration, and extreme temperatures.

Limiting Power Consumption

Solenoids and valves designed utilizing latching, peak & hold, or pulse width modulation control schemes to achieve minimal power consumption.

Minimized Footprint

Our engineers use their knowledge in solenoid design and materials to develop efficient solenoids that utilize the best control scheme for your application, resulting in a minimized footprint.

Quick-Turn Customization

Depending on your application requirements, TLX can offer quick-turn customization on our existing solenoid base models, or if needed, a complete customization to meet your needs.
