Pressure Release Solenoid Valve

This solenoid valve example is used for applications needing to quickly reduce pressure within an enclosed cavity or transmit fluid to another passage.

This on-off solenoid valve was designed for engines and applications that need to quickly reduce pressure within a cylinder, enclosed cavity or transmit fluid to another passage. The component works much like a small engine intake or exhaust valve. When power is applied, the inner poppet (valve) extends, communicating flow from the valve nose to the radial exit holes.

Typical Applications

Pressure Release Solenoid Valve

Features and Benefits

  • High operating temperature
  • Normally closed
  • Teon wires sleeved with a silicon jacket
  • Low leakage
  • Excellent wear characteristics
Downloads

All TLX components are customized to fit system requirements, meaning technical specifications are unique to each customer and design. Examples given on our website are for illustration purposes only.

Is our Pressure Release Solenoid Valve the right fit for your application?

TLX Technologies partners with the world’s top brands, first-tier suppliers, and OEMs. Contact our engineers today to discuss the details of your project.

Solenoids for Motorcycle Engines

A manufacturer needed an automatic compression release valve for a motorcycle engine. TLX Technologies designed a solenoid valve that met all the requirements and reduced total vehicle cost.

Our engineers begin by designing with 3D CAD and performing electromagnetic and fluid dynamic analysis with state-of-the-art finite element analysis software. Every design is engineered and tested in our lab to meet our customers’ specifications.

Increased Performance

Precise control with high accuracy through tighter tolerances. Reducing friction and inefficiencies provides extremely low hysteresis.

Lighter Weight

Multiple variables in the design and manufacturing process are optimized to reduce overall weight and size of the solenoid or valve.

Minimized Footprint

Custom solenoids can be designed to utilize the best control scheme for your application, resulting in a minimized footprint.

Limited Power Consumption

Latching technology in solenoid and valve design minimizes overall power consumption.

Extreme Environments

Can be designed to meet extreme environments that include moisture, dirt/dust, vibration and/or extreme temperature requirements.

Built-in Safety

Failsafe modes are designed into solenoids and valves utilizing integrated electronic controls.
