Three-Way Proportional Pressure Reducing-Relieving Valve

This proportional solenoid valve is a direct-acting, normally open, continuously variable pressure relief valve.

This proportional solenoid valve is a direct-acting, normally open, continuously variable pressure relief valve that can be designed to operate over various pressure ranges to optimize controllability. Connector and port cavity was configured for customer's requirements.

Typical Applications

Three-Way Proportional Pressure Reducing-Relieving Valve

Features and Benefits

  • Compact design
  • Fast response
  • Low differential pressure in stand-by
  • Can be designed for specific pressure ranges to optimize controllability
  • Can be designed to configure with customer electronic drivers
Downloads

All TLX components are customized to fit system requirements, meaning technical specifications are unique to each customer and design. Examples given on our website are for illustration purposes only.

Is our Three-Way Proportional Pressure Reducing-Relieving Valve the right fit for your application?

TLX Technologies partners with the world’s top brands, first-tier suppliers, and OEMs. Contact our engineers today to discuss the details of your project.

A Challenge to Durable Solenoid Design

TLX was approached with an application that called for a solenoid valve to operate while completely submerged in the hot automatic transmission fluid of an all-terrain vehicle...Easy right? Well, our engineers were up for the challenge.

Our engineers begin by designing with 3D CAD and performing electromagnetic and fluid dynamic analysis with state-of-the-art finite element analysis software. Every design is engineered and tested in our lab to meet our customers’ specifications.

Increased Performance

Precise control with high accuracy through tighter tolerances. Reducing friction and inefficiencies provides extremely low hysteresis.

Lighter Weight

Multiple variables in the design and manufacturing process are optimized to reduce overall weight and size of the solenoid or valve.

Minimized Footprint

Custom solenoids can be designed to utilize the best control scheme for your application, resulting in a minimized footprint.

Limited Power Consumption

Latching technology in solenoid and valve design minimizes overall power consumption.

Extreme Environments

Can be designed to meet extreme environments that include moisture, dirt/dust, vibration and/or extreme temperature requirements.

Built-in Safety

Failsafe modes are designed into solenoids and valves utilizing integrated electronic controls.
